Getting started

Table of Contents

Operating System 

Windows
Linux and macOS are also supported, provided APSIM is installed and running locally on your machine.

Python Requirements 

Python ≥ 3.10 and < 3.14

Note

Python 3.14 is not currently supported due to upstream limitations in pythonnet. However, the development team is working around the clock to make sure it is also supported

Required Dependencies 

APSIM (installed locally)
- APSIM must be installed and accessible on the system.
- A compatible APSIM version matching your workflow is required.
pythonnet ≥ 3.0.5
- Used to interface with APSIM’s .NET runtime.
NumPy
Pandas
SQLAlchemy
matplotlib and seaborn

These dependencies are installed automatically via pip.

Installing apsimNGpy 

You can install apsimNGpy using one of the methods below.

Method 1: Install from PyPI (stable releases)

pip install apsimNGpy

Method 2: Clone the development repository 

git clone https://github.com/MAGALA-RICHARD/apsimNGpy.git
cd apsimNGpy
pip install .

Method 3: Install directly from GitHub (Recommended)

pip install git+https://github.com/MAGALA-RICHARD/apsimNGpy.git

Tip

Installing directly from GitHub may be convenient for Anaconda users, as apsimNGpy is not currently distributed through the Anaconda package manager.

Editable installation (for developers)

git clone https://github.com/MAGALA-RICHARD/apsimNGpy.git
cd apsimNGpy
pip install -e .

Important APSIM installation and tutorial links 

Important

APSIM application can be installed by following the links below:

Windows: https://www.apsim.info/download-apsim/downloads/
macOS / Linux: https://apsimnextgeneration.netlify.app/install/
APSIM documentation: https://docs.apsim.info/

Tip

If you are new to using APSIM, try the following tutorials here.

Tip

Unless you have a specific reason to do otherwise, always use the pinned APSIM version (or an earlier compatible release) shown on the apsimNGpy home page (Download it here) to avoid forward-compatibility issues.

Verifying the APSIM Binary Path 

Using the command line to set or check the APSIM bin path 

apsim_bin_path -s

Automatic search 

apsim_bin_path --auto_search

Hint

Shortcut:

apsim_bin_path -a

Using Python 

from apsimNGpy import config
print(config.get_apsim_bin_path())

How apsimNGpy Locates APSIM Binaries 

Tip

apsimNGpy locates APSIM binaries using the following priority order:

User-supplied binary path
Environment variables
System PATH
Known installation directories

If no valid path is found, a ValueError is raised.

Setting or Updating the APSIM Binary Path 

Option 1: Manual configuration file 

Locate APSIMNGpy_meta_data in your home directory.
Open apsimNGpy_config.ini.
Update the apsim_location entry.

Option 2: Using the apsimNGpy config API (recommended)

from apsimNGpy.config import set_apsim_bin_path
set_apsim_bin_path(r"path/to/your/apsim/binary/folder/bin")

Option 3: Command-line update 

apsim_bin_path -u "path/to/your/apsim/binary/folder/bin"

or

apsim_bin_path --update "path/to/your/apsim/binary/folder/bin"

Verifying Successful Configuration 

from apsimNGpy.core.apsim import ApsimModel

Attention

If this import fails, verify the APSIM binary path and Python.NET setup.

Final Note

The APSIM binary path only needs to be set once and can be reused across projects. apsimNGpy also supports switching between multiple APSIM versions when required.

The quickest alternative for all the above is to temporarily provide the APSIM bin path using a context manager. This approach is useful for short scripts or interactive sessions and assumes that you do not import any other apsimNGpy modules as follows:

from apsimNGpy import Apsim
with Apsim("C:/APSIM/2025.05.1234/bin") as apsim:
    # all apsimNGpy objects are loaded to the instantiated Apsim class object
    with apsim.ApsimModel('Wheat') as model:
      model.edit_model(model_type="Models.Manager", model_name='Sow using a variable rule', Population =160)
      model.run()
      df= model.results

Use the env file in the context manager as follows

from apsimNGpy import Apsim
with Apsim(dotenv_path = './config/.env', bin_key ='APSIM_BIN') as apsim: # assumes that .env is in the config directory
    with apsim.ApsimModel('Wheat') as model:
    model.run()
    df= model.results

Highlight

All modules that require .Net or apsim binary path are loaded after initializing Apsim class

Apsim can also be used without with key word as follows:

from apsimNGpy import Apsim
apsim = Apsim(dotenv_path = './config/.env', bin_key ='APSIM_BIN') # assumes that .env is in the config directory
with apsim.ApsimModel('Soybean') as model:
    model.run()
    df= model.results

Note

Apsim class was added in version 1.5.0, and extends the capabilities provided by apsim_bin_context Therefore, if you are still using prior versions, you should use apsim_bin_context as follows:

from apsimNGpy.config import apsim_bin_context
with apsim_bin_context(apsim_bin_path ='your/apsim/bin'):
   # import any module now
   from apsimNGpy.core.apsim import ApsimModel
   model  = ApsimModel('Maize')
   model.run()
   df =model.results
